Indirect Low Pressure (ILP) Fire Suppression System

Indirect Low Pressure (ILP) Fire Suppression System
Indirect Low Pressure (ILP) Fire Suppression System

Description

KalpEX® Indirect Low Pressure (ILP) Fire Suppression Systems are engineered, fixed fire protection solutions designed to safeguard enclosed and semi-enclosed hazards where controlled agent distribution and extended coverage are required.

In an ILP system, the extinguishing agent is stored in a low-pressure cylinder and discharged through a piping and nozzle network, ensuring uniform and effective suppression across the protected area.


Based on 0 reviews. - Write a review
Rs 0.00
Ex Tax: Rs 0.00
  • Stock: In Stock
  • Model: KI - ILP
Enquire Now
  • Controlled and uniform suppression
  • Suitable for larger or multiple enclosures
  • Flexible system design
  • High reliability and long service life
  • Reduced fire damage and downtime
  • Compatible with multiple extinguishing agents


ILP Fire Suppression Systems are ideal for:

  1. Electrical rooms and switchgear rooms
  2. Generator enclosures
  3. Battery energy storage systems (BESS)
  4. Industrial machinery rooms
  5. Server rooms and telecom facilities
  6. CNC and production machinery
  7. Chemical and process areas
Sr. No. Particulars Clean Agent Capacity
1 kg 2 kg 3 kg 4 kg
1 Conformity LPS 1666 & UL 2166
2 Type Stored Pressure
3 Agent/Content Clean Agent (FK 5112/HFC236fa/HFC227ea) (UL Listed) / Dry Chemical Powder ABC Type (MAP 90%)
4 Vessel MOC Welded Low Carbon Steel (CE Certified) / Aluminum Alloy (UL & CE Certified)
5 Fire Detection Tube Special Formulated Tube (UL Recognized)
6 Distribution Nozzle and Piping Stainless Steel
7 Operating Head Material/Valve Indirect Valve (Plated Brass)
8 Isolation Ball Valve Stainless Steel (PED Certified)
9 Pressure Gauge Bourdon Type (Stainless Steel & Brass) (UL Recognized) / CE Certified
10 Pressure Switch Stainless Steel (UL Recognized)
11 Pneumatic Fittings Brass
12 Siphon Tube Aluminum Alloy
13 Elastomeric Seals/Label UL Recognized
14 Working Pressure 15–18 Bar 15–18 Bar 15–18 Bar 15–18 Bar
15 Discharge Duration 10 sec 10 sec 10 sec 10 sec
16 Protected Volume 1 m³ 2 m³ 3 m³ 4 m³
17 Expellant Medium UHP Nitrogen Gas
18 Burst Pressure >90 Bar
19 Test Pressure 35 Bar (Welded Low Carbon Steel) & 53 Bar (Aluminum Alloy)
20 Temp. Range (+) 20°C to (+) 55°C
